B021115.WAPW1
Cone Drive Right Angle Worm Gearbox
1.33" Center Distance
15:1 Ratio
NEMA 140TC Motor Adapter Input
0.75" Double Extended Output Shaft
Ratings Based On 1750 RPM Motor:
Output Speed (RPM): 117
Maximum Input Horsepower: 0.79
Maximum Output Torque: 325 lb-in
Efficiency: 76%
